Adopt the latest highest performance ADI 5 series processing chip , operating more fast and more accuracy ,sounds effect has much more improve too . The computer software comes with a professional-grade RTA spectrum display , feedback point more accurate and intuitive , debugging more convenient .
●Adopt ADI chip designed , 64-Bit fhigh-speed dicaryon DSP processor
●The Music channel has 9 segments PEQ stereo equalizer ,and Identify optical digital input automatically .
●The microphone has 15 segments PEQ adjustment , fully digital audio process system . Stereo DSP multiple digital reverb .The vocals are more professional
●Microphone mute setting . Independent compress / limit designed ; Optional 2Hz~8Hz frequency shift feedback suppression .and "OFF"optioned .
●The effect channel has high/low pass ; Reverb and echo has 5 segments of PEQ respectively...etc .
●Each output channel has 7 segments of PEQ respectively , high/low pass adjusted , mixing ratio , polarity ,delay , compress / limit , gain function .
●Support VOD IR interface controller
●Support RS232 connect to computer controller , comes with professional PC controlled software .
●It has RTA frequency spectrum display , to find the feedback point effectively to cancel the hawling .
●3 levels engineering password lock function ,The device lock level can be set by yourself accordingly.
●9 Groups system mode could be save , the turn on status is the data of the one which saved by last time .
parameter
MAX input electrical level for music： +14dBu（4V RMS）
MAX output electrical level for output CH： +14dBu（4V RMS）
Music gain： 0dB、+3dB、+6dB（optional）
Microphone sensitivity： 64mV（Out：4V）
S/N： ＞90dB
Power supplied： 220V/AC/50Hz
Size： 483*218.5*47.5mm
Net weight： 3.5KG
