FEATURE - Adopt ADI chip designed , 64-Bit high-speed dicaryon DSP processor. - The Music channel has 9 segments PEQ stereo equalizer ,and Identify optical digital input automatically . - The microphone has 15 segments PEQ adjustment , fully digital audio process system . Stereo DSP multiple digital reverb .The vocals are more professional. - Microphone mute setting . Independent compress / limit designed ; Optional 2Hz~8Hz frequency shift feedback suppression .And "OFF" optioned. - The effect channel has high/low pass ; Reverb and echo has 5 segments of PEQ respectively...etc. - Each output channel has 7 segments of PEQ respectively , high/low pass adjusted , mixing ratio , polarity ,delay , compress / limit , gain function. - Support VOD IR interface controller . - Support RS232 connect to computer controller , comes with professional PC controlled software . - It has RTA frequency spectrum display , to find the feedback point effectively to cancel the hawling . - 3 levels engineering password lock function ,The device lock level can be set by yourself accordingly. - 9 Groups system mode could be save , the turn on status is the data of the one which saved by last time .
PARAMETER MAX input electrical level for music：+14dBu（4V RMS） MAX output electrical level for output CH：+14dBu（4V RMS） Music gain：0dB、+3dB、+6dB Microphone sensitivity：64mV（Out：4V） S/N：＞90dB Power supplied：220V/AC/50Hz Size： 483*218.5*47.5mm Net weight ： 3.8KG
